Availability: | |
---|---|
Quantity: | |
Model | GDF-10L | GDF-15L | GDF-20L |
---|---|---|---|
Operating System | 5.5-inch color touch screen | ||
Number of Sample Holes | 10 holes | 15holes | 20holes |
Aperture | Φ43.5mm | ||
Heating Module Material | 6061 aluminum alloy | ||
Designed Temperature | 400℃ | ||
Temperature Control Accuracy | ±1℃ | ||
Heating Rate | ≈6-15℃/min | ||
Control Mode | Single point heating | ||
Recipe Management | 9 groups | ||
Timing Shutdown | 1-999 minutes | ||
Power Supply | AC220V/50Hz | ||
Heating Power | 2KW | 3KW | 4KW |
Size(W×D×H)(mm) | 439x387x533 | 490x387x533 | 542x387x533 |
Shipping Size(W×D×H)(mm) | 690x530x650 | ||
N.W./G.W. (kg) | 18/27 | 21/31 | 26/35 |
Over-temperature protection sensor on the shell's surface: when the furnace body's surface temperature is too high, it will automatically alarm and stop.
High-definition display direct setup, easy and fast operation
The colors of the function pages are differentiated from those of the application pages for easy identification.
Single-point heating, curve heating dual mode optional
Segmented power supply, anti-power failure recovery, and restart function can avoid potential risks.
