Model | SP-AA4530 |
---|---|
Wavelength Range | 190-900nm |
Spectral Bandwidth | 0.1/0.2/0.4/1.0/2.0 nm |
Accuracy of the Wavelength | ±0.15nm |
Receptivity of the Wavelength | ≤0.04nm |
Base Line Stability | ≤0.002A/30min (Cu) |
Characteristic Viscosity | 0.02μg/ml/1% (Cu) |
Checking Limit | 0.004μg/ml (Cu) |
Preciseness | 0.005 |
Grating | 1800 lines/mm |
Inflamer | All-metal titanium burner |
Atomizer | Effective glass atomizer |
Lamp Stand | 8 |
D2 Background Correction Ability | When the background is 1A, the background ability should be deducted not less than 50 times, self absorption background deduction method |
Power Source | 220V±22V AC |
Shipping Size(W×D×H)(mm) | 860×705×755(Main instrument) |
1170×645×900(Accessories) | |
G.W. (kg) | 105 (Main instrument); 100 (Accessories) |
Flame System | |
Acetylene Air Burner | 100mm |
Lgnition Dynamic Baseline Drift | ≤0.006A/30min |
(Cu) Characteristic Viscosity | ≤0.025μg/ml/1% |
Related Standard Deviation of the Accuracy | ≤0.5% (Cu, absorbance>0.8A) (detection limit Cu≤0.008μg/ml) |
Safety System | Can automatically cut off the gas when the pressure is not enough the power is off flame out and unconformity of the burner |
Graphite Furnace | |
The Highest Temperature | 3000℃ |
The Largest Temperature Rising Speed | ≥2000℃/s |
Characteristic Quantity | Cd≤0.5×10-12g Cu≤0.5×10-11g |
Accuracy | Cu≤3% Cd≤3% |
Size (mm) and Weight | 730×625×700; 79.3kg |
Safety System | Over current protection |
Low air pressure alarm/protection | |
Low cooling water flow alarm/protection | |
Power Source and Power | 220V±22V AC 7000W |
The atomic absorption spectrophotometer is PC-controlled and uses advanced graphite furnace temperature control technology. Its unique optical and mechanical design and various convenient features make it ideal for various industries. Here are some of its features:
1. Complete automatic control system, fully PC controlled. You can quickly realize:
Automatic ignition and extinguishing
Graphite furnace test method setting wavelength scanning and peak seeking determination
Selection of atomizer
Gas flow control
Advanced graphite furnace temperature control technology
The setting of the background deduction method
Elevator up and down front and back adjustment
Adjustment of light energy
2. Integrated floated optical platform design can improve the visual system shock resistance and keep it stable though using the optical signal for a long time.
3. The flame burner can automatically adjust the optimum height
4. Simultaneous preheating of eight lamps with automatic change of selection
5. Fully automatic peak search and wavelength scanning
6. Full range of safety features, including flame anomalies, gas leaks, under-pressure alarms and automatic safety protection.
7. Self-absorbing background and deuterium lamp adjustment
8. Superior data processing capability
Advanced Graphite Furnace Temperature Controlling Technology
1. PID technology ensures more accurate temperature control even with voltage fluctuations and resistance changes.
2. Fast sampling techniques are used to obtain reliable test data
3. The furnace has a fast heat-up capability for increased component flexibility
4. It can be powered by a 220V power supply with a maximum heating capacity set to 20 levels for testing different samples
5. Can adjust the gas flow to three different levels to suit a variety of applications
6. The Atomic absorption spectrophotometer has an alarm system that alerts the user during a low gas or water supply.
Safe and reliable flame system
1. EPC for more precise control of acetylene (C2H2) flow and easier handling
2. Highly efficient atomization system for higher sensitivity
3. High safety with automatic alarms for flame anomalies, power failures, insufficient pressure, etc.
4. Automatic gas shut-off in case of abnormality
Multifunctional Software Workstation
Supports WINDOWS7
1. Rich menus make operation more convenient
2. Convenient conversion between different menus makes the process easier.
3. Multiple analysis and correction methods provide users with more choices.
4. Supports flexible storage and editing
