Stackable CO2 Incubator

Model : ICB-160SC; ICB-270SC

Mode : Six-sided direct heating air jacket type
Temperature Range : RT+5°C-60°C
Sterilization Mode : 90°C damp-heat (optional 140°C dry-heat sterilization)
CO2 Control Scope : 0.1-20%
Humidification Mode : Natural evaporation (injecting sterile distilled water into the bottom tank of the cavity)
Availability:
Quantity:

Stackable CO2 Incubator Specifications:

ModelICB-160SCICB-270SC
Temperature
Control
ModeSix-sided direct heating air jacket type
Temperature RangeAmbient temperature: +5°C-60°C
Temperature Stability±0.5°C (at 37°C)
Temperature Accuracy±0.1℃
Temperature Recovery Time≤ ±10mins
Ambient Temperature Range10℃-30℃
CO2  Concentration
Control
CO2 Control Scope0.1-20%
CO2 Control Accuracy0.10%
CO2 Stability±0.1℃
CO2 Accuracy±0.3%
CO2 SensorGermany imported infrared ray (IR) sensor
Sterilization Mode90°C damp-heat (optional 140°C dry-heat sterilization)
Concentration Recovery
Time
≤5Mins, door opened for 30S
Humidity ControlModeNatural evaporation (injecting sterile distilled water into the bottom tank of the cavity)
Temperature Range45%-94%
Door Opening Recovery15mins
Technical
Specification
Capacity160L270L
Number of Shelves3/74/8
Shelf Size466x426mm520x524mm
Heating Power800W1000w
Power Supply220V,50/60Hz;110V,60Hz
Maximum Stacking2 sets2 sets
Internal Size (WxDxH mm)492x515x630622x560x782

External Sizes

(W×D×H mm)

620x800x810750x730x950

Shipping Size

(W×D×H mm)

920x730x990920x870x1150
N.W./G.W. (kg)72/11099/160
Technical FeaturesDisplay Mode5-inch true color touch screen
Control ModeP.I.D microcomputer environment scanning microprocessor chip control
Placement PositionOn/off the experimental table, landing or stacking
Inner Glass DoorStandard single inner door (inner door heating)
Ambient Temperature10℃-30℃
Temperature ProbeSeparate
CleanlinessMoist-heat sterilization at 90°C
HEPA filter (optional)
The intake gas is sterilized by a 0.2um online filter
Data ExportUSB interface (optional)
Optional AccessoriesCavity, liquid tray, shelf
Relative Humidity<95%
Remote ControlExtensible computer remote wireless monitoring and mobile APP monitoring (optional)
Luxury StylePatented modeling with extremely aesthetic design, mold design and manufacturing
technology, integrating appearance and practicality

ICB-SC series stackable CO2 Incubator are the most perfect culture equipment for biological culture, suitable for animal cell culture, germ cell culture and anaerobic cell culture, and also suitable for the culture and incubation experiments of all microorganisms, and the seed cultivation and tissue culture experiments.

Widely used in cytology, histology, immunology, medicine, biology, molecules, biomedicine, fermentation, biochemical reaction, hybridization and other research fields.

Stackable CO2 Incubator Feature:

  1. PID microcomputer environment scanning control technology

  2. Six-sided heating design of direct heating air jacket

  3. Liner full fillet stainless steel material

  4. Air intake filter design and Built-in HEPA high efficiency filter

  5. CO2 Infrared sensor

  6. High temperature sterilization function

  7. Design of preventing condensed water

  8. Audible and visual alarm function, alarm information recording and query function

  9. Meet GMP customer requirements

  10. Real-time data query function and powerful data storage function

  11. Temperature real-time curve display function and USB drive export data function
