Availability: | |
---|---|
Quantity: | |
Model | NG-300 | NG-500 |
---|---|---|
Nitrogen Purity | 0.9999 | |
Output Flow | 0~300ml/min, 0~500ml/min | |
Output Pressure | 0 ~ 0.6Mpa (Generally set to 0.4Mpa ±0.01Mpa when leaving the factory) | |
Water Quality | Purified water, distilled water or deionized water | |
Power Supply | AC220/110V, 50/60Hz | |
Max. Power | 150W | |
Size (W×D×H)(mm) | 425×210×365 | |
Shipping Size (W×D×H)(mm) | 450x300x470 | 350x330x510 |
N.W./G.W. (kg) | 10/13 | 10/14 |
Just access compressed air and turn on the power switch to generate high-purity nitrogen
The electrolytic cell has large electrolysis area, low cell temperature and long service life
Nitrogen generator equipped with non-returning liquid device to ensure that the instrument has no liquid returning phenomenon
Manual emptying is more reliable, and it has the function of automatically closing the gas circuit when power is cut off
The method of first stabilizing pressure and then stabilizing flow is adopted, with higher accuracy of output pressure and flow, stable and fast chromatographic baseline and low noise
Model | NG-300 | NG-500 |
---|---|---|
Nitrogen Purity | 0.9999 | |
Output Flow | 0~300ml/min, 0~500ml/min | |
Output Pressure | 0 ~ 0.6Mpa (Generally set to 0.4Mpa ±0.01Mpa when leaving the factory) | |
Water Quality | Purified water, distilled water or deionized water | |
Power Supply | AC220/110V, 50/60Hz | |
Max. Power | 150W | |
Size (W×D×H)(mm) | 425×210×365 | |
Shipping Size (W×D×H)(mm) | 450x300x470 | 350x330x510 |
N.W./G.W. (kg) | 10/13 | 10/14 |
Just access compressed air and turn on the power switch to generate high-purity nitrogen
The electrolytic cell has large electrolysis area, low cell temperature and long service life
Nitrogen generator equipped with non-returning liquid device to ensure that the instrument has no liquid returning phenomenon
Manual emptying is more reliable, and it has the function of automatically closing the gas circuit when power is cut off
The method of first stabilizing pressure and then stabilizing flow is adopted, with higher accuracy of output pressure and flow, stable and fast chromatographic baseline and low noise
