Model | KDF-220F |
---|---|
Temperature Range | RT +5 - 450℃ |
Temperature Accuracy | ±1℃ |
Heating Method | Infrared heating and high-purity graphite conduction |
Heating Insulation Method | Unique air duct insulation technology |
Digestion Tube Capacity | 300mL |
Capacity | 20pcs/batch |
Power Supply | 220 VAC±10% 50HZ |
Power | 3600W |
Size(W×D×H)(mm) | 515×421×211 |
Shipping Size(W×D×H)(mm) | 680x600x530 |
N.W./G.W. (kg) | 25/40 |
KDF-220F has two temperature control modes: curve heating and linear temperature heating.
10 groups of digestion procedures can be edited and stored. Each group can set up to 5 temperature and time gradients to meet the different experimental needs of users.
Graphite block is treated with special anti-oxidation treatment for a longer service life.
Adopting advanced PID temperature control technology, it only takes 20 minutes to raise the temperature to 400℃ with high precision.
Adopt a PFA sealing cover, longer service life, and good treatment effect. Clip-type sealing cover, easy to replace.
Adopting a special water jet vacuum pump means no need for electricity. The drip tray design reduces corrosion damage from acid solution.
Use microwave reaction system for pre-treatment before microwave digestion or deacidification after digestion.
