Halogen Moisture Analyzer

Model : BA-HM005; BA-HM105; BA-HM102; BA-HM101

Capacity : 50g / 100g / 100g / 100g
Readability : 0.001g / 0.005g / 0.002g / 0.001g
Moisture Range : 0~100%
Accuracy for Moisture Measure : ±0.5% (Sample≥5g)
Moisture Readability : 0.02% / 0.02% / 0.01% / 0.01%
Scale Pan Size : Φ100mm
For routine moisture determination in the laboratory and in production. This halogen moisture analyzer measures moisture content in minutes for fast response for quality control and process control.
Availability:
Quantity:

Halogen Moisture Analyzer Specifications:

Model BA-HM005 BA-HM105 BA-HM102 BA-HM101
Capacity 50g 100g 100g 100g
Readability 0.001g 0.005g 0.002g 0.001g
Moisture Range 0~100%
Accuracy for Moisture
Measure
±0.5% (Sample≥5g)
Moisture Readability 0.02% 0.02% 0.01% 0.01%
Repeatability 0.2% 0.2% 0.0% 0.0%
Interface None RS232 Interface
Scale Pan Size Φ100mm
Heating Way High efficiency halogen lamp
Heating Time 1~99 minutes interval of 1 seconds
Time End Control Mode Auto Stop / Timed stop
Sample Drying Record 8 times
Temperature Range 60~160℃
Temp.Increase Step ±1℃
External Size (W×D×H) 205x325x170mm
Shipping Size (W×D×H) 325x460x295mm
Net Weight 2.9kg
Gross Weight 4.9kg

Halogen Moisture Analyzer Features:

  1. 5.5'' LCD touch screen.

  2. Aluminum alloy base and ABS shell.

  3. Timer dry / Auto dry function.

  4. RS232 interface, support to connect with printer and PC.

Details of halogen moisture analyzer:

BA-HM005 (14)

BA-HM005 (15)

BA-HM005 (7)

Halogen moisture analyzer have a simple design with an easy-to-use control panel and a clear display. There is an electrical plug on the back. The equipment is also equipped with an efficient internal exhaust system to ensure accuracy and reliability during the analysis process.

IMG_5715

BA-HM005 (17)

Calibration and analysis weights, sample trays, power cords

Above picture is BA-HM005


IMG_5723

IMG_5727

IMG_5737

Above picture is BA-HM101

Application of halogen moisture analyzer:

  1. Moisture analysis in food products

  2. Determination of moisture content in pharmaceuticals

  3. Testing moisture levels in cosmetics and personal care products

  4. Quality control in manufacturing processes for chemicals and plastics

  5. Measurement of moisture content in agricultural products such as grains and seeds

  6. Moisture analysis in environmental samples like soil and sediment

  7. Monitoring moisture levels in building materials like wood, concrete, and gypsum board.
