Dual-beam system, dual detectors, the use of high-performance imported grating, lower stray light, more reliable, stable, analysis and more accurate
Equipped with 10-inch touch screen, built-in 32G memory, support for Bluetooth connection
Built-in mainframe can enter the calibration curve
Adopts the suspension design of the optical system, 16mm thick aluminum non-deformation base to prevent deformation.
Powerful storage function, can be directly connected to the printer for A4 format data and graphics printing
With automatic start function, calibration, and system positioning function.
Can export data to U disk.
Model | SP-DUV8000 | SP-DUV8000I |
---|---|---|
Wavelength Range | 190-1100nm | |
Spectral Bandwidth | 1.8 nm | 0.5, 1.0 2.0, 4.0nm |
Wavelength Accuracy | ±0.1nm (D2 656.1nm), ±0.3 nm full range | |
Stray Light | 0.03% T @ 220 nm, 360 nm | |
Wavelength Repeatability | ≤0.1nm | |
Photometric Accuracy | ±0.2T(0-1009%T) | |
±0.002Abs(0-0.5Abs) | ||
±0.004Abs(0.5-1.0Abs) | ||
Photometric Repeatability | ≤0.05%6T(0-100%6T) | |
0.001Abs(0-0.5Abs) | ||
0.002Abs(0.5-1.0Abs) | ||
Stability | ±0.0004A/h@500nm | |
Photometric Range | 0-200%T, -0.3-3.0A, 0-9999C | |
Baseline Flatness | ±0.001A | |
Noise | ±0.0004A | |
Display | 800x480 touch screen | |
Data Output Port | USB | |
Print Port | USB Port | |
Light Source | Tungsten Lamp & Deuterium Lamp | |
Power Requirements | AC220V/50Hz or 110v/60Hz | |
Detector | Silicon Photodiode | |
Size(W×D×H)(mm) | 630x430x210 | |
Shipping Size(W×D×H)(mm) | 850x650x450 | |
N.W./G.W. (kg) | 28/38 |
