Thermal Cycler Specifications:
| Model | PCR-TC4852T |
|---|
| Capacity | Double 48×0.2ml |
| Temperature Range | 0-100℃ |
| Heating Rate | 5℃/s |
| Cooling Rate | 4℃/s |
| Uniformity | ≤±0.2℃ |
| Accuracy | ≤±0.1℃ |
| Display Resolution | 0.1℃ |
| Temperature Control | Block/Tube |
| Ramping Rate Adjustable | 0.1-5℃ |
| Gradient Temp. Range | 30-100℃ |
| Gradient Spread | 1-30°C |
| Hot Lid Temperature | 30-110°C |
| Number of Programs | 10000+(USB FLASH) |
| Max. No.of Step | 30 |
| Max. No.of Cycle | 100 |
| Time. Increment/Decrement | 1 sec-600 sec |
| Temp. Increment/Decrement | 0.1-10.0℃ |
| Pause Function | Yes |
| Auto Data Protection | Yes |
| Hold at 4℃ | Forever |
| Touchdown Function | Yes |
| Long PCR Function | Yes |
| Language | English |
| Computer Software | Yes |
| Mobile Phone APP | Andriod |
| LCD | 8 inch, 800×600 pels |
| Communication | USB 2.0, LAN |
| Power Supply | AC100-240V, 50/60Hz, 600W |
| Size(W×D×H)(mm) | 390×270×255 |
| Shipping Size(W×D×H)(mm) | 570x440x440 |
| N.W./G.W. (kg) | 8.5/15 |
Thermal Cycler Features:
The PCR-TC4852T thermal cycler has a maximum temperature increase rate of 5°C/s, which is excellent enough to meet higher experimental demands. 8 long-life Peltier heating units, all made in the USA, can form 4 circuits and control 4 temperature zones, greatly improving the accuracy and reliability of the PCR thermal cycler reaction. Reliability of PCR thermal cycler reaction.
It has anodized reinforced aluminum modules for corrosion resistance and fast thermal conductivity.
High cooling and heating rates save operating time
The lid of the PCR instrument can be adjusted according to the desired temperature, allowing for more precise control of the temperature inside the tubes.
The thermal cover is equipped with a protective mechanism to control the pressure inside the test tube, preventing the test tube from breaking or being damaged due to excessive pressure.
Adaptable to different heights of tubes to ensure close contact between the tube and the lid to avoid melting or evaporation of the tube.
Built-in 11 standard program file templates and supports storing 10,000 PCR files and USB transfer data.
Real-time display of running programs and time remaining, allowing editing of files while the program is running.
Auto restart after power failure and continue to run unfinished programs when power is restored.
One-button rapid incubation function to meet the needs of denaturation, digestion/enzymatic coupling, ELISA, and other experiments.
