LCD display with bright illumination
Automatic defrost function
High precision speed and temperature control
Door open protection
Memorized and protected operating parameters
Function of encrypted and locked operating parameters
Continuously running or timing
Unique slow-start design、unique drive system and advantaged air duct design
High quality servo motor
Multi-steps rotate speed, temperature and time control systems
Slow accelerate and decelerate design
Automatic analyzing, listing table, charting and printing on downloaded dates.
Model | ICB-70BS | ICB-70BSI |
---|---|---|
Display | LCD display | |
Controller | PID | |
Circulation Mode | Forced convection | |
Shaking Mode | Convolution | |
Drive Mode | Unidimensional drive | |
Capacity(L) | 70L | |
Temperature Range(℃) | RT+5~65℃ | 4~65℃ |
Temperature Accuracy(℃) | ±0.1℃ | |
Temperature Uniformity(℃) | ±0.5℃(at 37℃) | |
Cyclotron Frequency Range (rpm/min) | 20-450(r/min)(To do static culture) | |
Cyclotron Frequency Sensitivity (rpm) | ±1 | |
Orbit Range (mm) | Φ26 | |
Refrigerant | / | Environmentally friendly refrigerant |
Timing Range (h/min) | 0-9999h/min | |
Standard Capacity | Clamp flask: 50mlx4+100mlx4 + 250mlx3+500mlx3 | Clamp flask: 50mlx5+100mlx5 + 250mlx4+500mlx3 |
Max. Capacity | Clamp flask:100ml x23 or 250ml x15 or 500ml x9 or 1000ml x6 or 2000ml x4 | |
Auxiliary Functions | Ultra-low speed start, Adjustable start speed, Overspeed auto-prtection, Automatically stop when opening the door, Monitoring timer, Parameters Storage, Encryption parameters, Electricity incoming recovery, Refrigeration unit overload protection, Sound and light alarm when upper and lower overtemperature | |
External and Internal Material | Stainless steel | |
Power Supply | AC220V±10%, 50/60Hz;110V, 60Hz | |
Consumption | 550W | 650W |
Shaking Plate Size(mm) | 450x410 | |
Size(W×D×H)(mm) | 750x710x520 | |
Shipping Size (W×D×H)(mm) | 900x895x725 | |
N.W./G.W. (kg) | 75/125 | 110/145 |
